The Dell EMC PowerEdge R750xa is a purpose-built server designed to deliver accelerated performance across the broadest range of customer needs.
The Dell EMC PowerEdge R750xa delivers compelling performance, high-speed memory and capacity, and exceptional support for a wide range of GPU products —
ideal for:
• AI/ML/DL Training and Inference
• High-Performance Computing
• Virtualization
Scaling Innovation for Challenging and Emerging Workloads
The Dell EMC PowerEdge R750xa (powered by 3rd Gen Intel® Xeon® Scalable processors) is a dual-socket/2U rack server delivering outstanding performance for the most demanding emerging and GPU-intensive workloads. It supports 8 channels per CPU and up to 32 DDR4 DIMMs operating at 3200 MT/s. Furthermore, to deliver tangible throughput improvements, the PowerEdge R750xa supports PCIe 4.0 and up to 8 SAS/SATA SSDs or NVMe drives. Supporting all PCIe GPUs in the PowerEdge portfolio with a single platform makes the PowerEdge R750xa the ideal server for emerging workloads including AI ML/DL training and inference, high-performance computing, and virtualization environments.
Boost efficiency and accelerate operations through autonomous collaboration
The Dell EMC OpenManage Systems Management portfolio addresses management complexity and safeguards IT infrastructure. Using Dell Technologies' intuitive end-to-end tools, IT teams can deliver a secure, integrated experience by reducing processes and information silos, enabling them to focus on business growth.
EMC OpenManage portfolio is the engine of innovation, leveraging tools and automation to help you scale, manage, and protect your technology environment.
• Built-in telemetry streams, thermal management, and Redfish-compliant RESTful APIs deliver simplified visibility and manageability for enhanced server management
• Intelligent automation enables collaboration between human operations and system functions to boost productivity
• Integrated change management for update planning and seamless zero-touch configuration and deployment
• Full stack management integration with Microsoft, VMware, ServiceNow, Ansible, and many other tools
Protect your data assets and infrastructure with proactive resilience
The Dell EMC PowerEdge R750xa server is designed with a network resilience architecture that deeply integrates security into every stage of its lifecycle, from design through retirement.
• Run your workloads on a secure platform built on cryptographic-based trusted boot and silicon-based root of trust
• Maintain server firmware security with digitally signed firmware packages
• Prevent unauthorized configuration or firmware changes through system locking
• Securely and rapidly erase all data from storage media, including SSDs and system memory, using the system wipe feature
| Processor | Up to two 3rd Generation Intel Xeon Scalable processors, with up to 40 cores per processor |
| Memory |
• 32 DDR4 DIMM slots, supports RDIMM 2 TB max or LRDIMM 8 TB max, speeds up to 3200 MT/s • Up to 16 Intel Persistent Memory 200 series (BPS) slots, 8 TB max • Supports registered ECC DDR4 DIMMs only |
| Storage controllers |
• Internal controllers: PERC H745, HBA355I, S150, H345, H755, H755N • Boot Optimized Storage Subsystem (BOSS-S2): HW RAID 2 x M.2 SSDs 240 GB or 480 GB • Boot Optimized Storage Subsystem (BOSS-S1) HW RAID 2 x M.2 SSDs 240 GB or 480 GB • External PERC (RAID): PERC H840, HBA355E |
| Drive Bays |
Front bays: • Up to 8 x 2.5-inch SAS/SATA (SSD) max 122.88 TB • Up to 6 x 2.5-inch NVMe (SSD) max 92.1 TB |
| Power Supplies |
• 1400 W Platinum AC/240 HVDC • 2400 W Platinum AC/240 HVDC |
| Cooling Options | Air cooling, optional processor liquid cooling |
| Fans |
• System Fan (60 x 76 mm) • Up to six hot plug fans |
| Dimensions |
• Height – 86.8 mm (3.41 inches) • Width – 482 mm (18.97 inches) • Depth – 894.8 mm (35.22 inches) - without bezel 908.64 mm (35.77 inches) - with bezel |
| Form Factor |
2U rack server |
| Embedded Management |
• iDRAC9 • iDRAC Service Module • iDRAC Direct • Quick Sync 2 wireless module |
| Bezel |
Optional LCD bezel or security bezel |
| OpenManage Software |
• OpenManage Enterprise • OpenManage Power Manager plugin • OpenManage SupportAssist plugin • OpenManage Update Manager plugin |
| Mobility |
OpenManage Mobile |
| Integrations and Connections |
OpenManage Integrations • BMC Truesight • Microsoft System Center • Red Hat Ansible Modules • VMware vCenter and vRealize Operations Manager OpenManage Connections • IBM Tivoli Netcool/OMNIbus • IBM Tivoli Network Manager IP Edition • Micro Focus Operations Manager • Nagios Core • Nagios XI |
| Security |
• Cryptographically signed firmware • Secure Boot • Secure Erase • Silicon Root of Trust • System Lockdown (requires iDRAC9 Enterprise or Datacenter) • TPM 1.2/2.0 FIPS, CC-TCG certified, TPM 2.0 China NationZ |
| Embedded NIC |
2 x 1 GbE LOM |
| Network Options |
1 x OCP 3.0 (x8 PCIe lanes) |
| GPU Options |
Up to two double-width 300 W, or three single-width 150 W, or six single-width 75 W accelerators |
| Ports |
Front Ports • 1 x Dedicated iDRAC Direct micro-USB • 1 x USB 2.0 • 1 x VGA Rear Ports • 1 x USB 2.0 • 1 x Serial (optional) • 1 x USB 3.0 • 2 x RJ-45 • 1 x VGA (optional for liquid cooling configuration) |
| Internal Ports |
• 1 x USB 3.0 |
| PCIe |
Up to 8 x PCIe 4.0 slots (up to 6 x16 + 2 x8) |
| Operating System and Hypervisors |
• Canonical Ubuntu Server LTS • Citrix Hypervisor • Microsoft Windows Server with Hyper-V • Red Hat Enterprise Linux • SUSE Linux Enterprise Server • VMware ESXi |
