The HPE ProLiant DL320 Gen12 maximizes your rack utilization while mitigating virtualization risks in power-constrained environments. Power your workloads with a server providing greater expansion capabilities compared to previous generations. The latest Intel® Xeon® 6 processors with up to 144 cores, increased memory capability (up to 4 TB), and highspeed PCIe Gen5 help provide a high performance solution with better datacenter efficiency.
Do you need a 1U single socket rackmount server, that maximizes rack utilization while mitigating virtualization risks in power-constrained environments?
The HPE ProLiant DL320 Gen12 maximizes your rack utilization while mitigating virtualization risks in power-constrained environments. Power your workloads with a server providing greater expansion capabilities compared to previous generations. The latest Intel® Xeon® 6 processors with up to 144 cores, increased memory capability (up to 4 TB), and highspeed PCIe Gen5 help provide a high performance solution with better datacenter efficiency.
•Next-Level Security, Chip to Cloud
•Optimized Performance for your Workloads: Accelerated, Open, and Efficient
•Intuitive Cloud Operating Experience: Simple, Self-service, and Automated
•Industry-leading Services and Ease of Deployment
|
MODEL |
HPE ProLiant Compute DL320 Gen12 |
|
Processor family |
Intel® Xeon® 6 processors |
|
Processor core available |
8 to 144 core, depending on processor |
|
Processor cache |
48 to 336 MB L3, total, depending on processor |
|
Processor number |
1 |
|
Processor speed |
3.5 GHz maximum, depending on processor |
|
Maximum memory |
4.0 TB, when populated with 256 GB DDR5 Memory |
|
Memory slots |
16 |
|
Memory type |
HPE DDR5 Smart Memory |
|
Drive supported |
Up to 8+2 SFF SAS/SATA HDDs or SATA/SAS/NVMe U.2 or U.3 SDDs, depending on model. Up to 12 LFF SAS/SATA HDDs or SSDs, depending on the model. Up to 20 EDSFF E3.s 1T, depending on model. Optional RAID 1 NVMe M.2 Boot device (Internal or external accessible from rear wall or front cage with 2x NVMe M.2 incorporated, depending on model). |
|
Optical drive type |
Optional DVD-ROM / DVD-RW Optical Drive |
|
Security |
UEFI Secure Boot and Secure Start support. Intel® Software Guard Extensions (SGX) support. Intel® Trust Domain Extensions (Intel®TDX) . Immutable Silicon Root of Trust. Optional Trusted Supply Chain, iLO Security modes, TPM, Chassis Intrusion detection and |
|
Infrastructure management |
HPE iLO Standard with Intelligent Provisioning (embedded), HPE OneView Standard (requires download), HPE iLO Advanced, HPE iLO Advanced Premium Security Edition, and HPE OneView Advanced (require licenses), HPE Compute Ops Management (subscription included) |
|
Power supply type |
1000W, 1500W, or 2400W Titanium Hot Plug Modular - Common Redundant Power Supply (M-CRPS) |
|
Expansion slots |
Up to 6 PCIe Gen5, and 2 OCP 3.0 with Rich IO Processor, for detailed descriptions reference the QuickSpecs |
|
Network controller |
Wide range of speeds, cabling, chipsets and form factors (PCIe stand-up adapter and OCP3.0). Please refer to the QuickSpecs for network card choices. |
|
Storage controller |
Optional - HPE MR216i-o, MR216i-p, MR408i-o, MR408i-p, MR416i-o, and MR416i-p storage controllers. Please refer to the QuickSpecs for storage controller selection. |
|
System fan features |
Standard Fan Kit or High Performance Fan Kit, depending on model |
|
Form factor |
1U Rack |
