Models
|
GS 2024U
|
|
Specification
|
2U 24-bay
|
|
Controller
|
Dual Redundant
|
|
Cache Backup Technology
|
Super capacitor + Flash Module
|
|
Cache Memory
|
Default DDR4 16GB, up to 128GB
|
|
Host Board Options
|
* 16Gb/s FC x 4
* 32Gb/s FC x 2
* 32Gb/s FC x 4
* 10GbE (SFP+) x 2
* 25GbE (SFP28) x 2
* 25GbE (SFP28) x 4
* 12Gb/s SAS x 2
|
|
Supported Drives
|
2.5” U.2 NVMe SSD (must be purchased from Infortrend)
|
|
Max. Drive Number
|
Per appliance: 896 (via expansion enclosures)
Per cluster: 3,584 (via scale-out with other series of appliances)
|
|
RAID Options
|
RAID 0, RAID 1, RAID 3, RAID 5/5F, RAID 6/6F, RAID 10, RAID 30, RAID 50, RAID 60
|
|
Efficiency
|
Inline compression, offline deduplication
|
|
Data Services
|
Default software features include:
* Thin provisioning
* Scale-out (file level): 1 appliance per cluster
* Scale-out (block level): 4 appliances per cluster
* Snapshot (block level): 64 per source volume, 128 per system
* Local replication: 4 per source volume, 16 per system
* Remote replication (file level): support Rsync with 128-bit SSH encryption
Optional software features require additional license:
* Automated storage tiering: 4 tiers per pool
* Advanced scale-out (file level): 4 appliances per cluster
* Advanced snapshot (file level): 1,024 per folder
* Advanced snapshot (block level): 256 per source volume, 4,096 per
system
* Advanced local replication: 8 per source volume, 256 per system
* Advanced remote replication (block level): 8 per source volume, 64 per
system
|
|
Supported OS
|
Microsoft Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise, Sun Solaris, macOS X, VMware
|
|
Supported Protocols
|
File level: CIFS/SMB (version 2.0/3.0), NFS (version 2/3/4), AFP (version 3.1.12), FTP/FXP (vsftp 2.3.4), WebDAV (httpd package 2.4.6)
Block level: FC, iSCSI, SAS
Object level: RESTful API
|
|
Cloud Gateway
|
EonCloud Gateway supports integration with the following cloud providers:
* Amazon S3
* Microsoft Azure
* Alibaba Cloud
* Google Cloud
* Baidu Cloud
* Tencent Cloud
* OpenStack
* Wasabi
* Yandex
* hiCloud
* Backblaze Cloud
|
|
Management
|
* Web-based EonOne management software
* User account management
* Group management
* Folder management - folder access control
* Quota management
* Folder encryption with AES
* Integration with Microsoft Active Directory (AD) and Linux LDAP
* Storage Resource Management to analyze history records of resource usage
* Multi-factor authentication login mechanism
* File-level QoS (network traffic control)
* SMI-S standard interface for hypervisor management applications
|
|
Notification
|
Email, SNMP traps
|
|
Applications
|
Infortrend offers a wide range of applications for common enterprise needs. For detailed information, please refer to the Applications for GS webpage.
|
|
Expansion Enclosures (JBODs)
|
JB 3012A, JB 3016A, JB 3024BA, JB 3025BA, JB 3060L, JB 3090
|
|
Dimensions (W x H x D)
|
449 x 88 x 500 mm (without chassis ears and protrusions)
|
|
Package Dimensions (W x H x D)
|
780 x 338 x 588 mm
|
×
