The Dell PowerEdge R470 is powered by Intel Xeon 6 Processors, DDR5 Memory, NVMe BOSS, Energy Star compliant and advanced cooling.
The Dell PowerEdge R470 is powered by Intel Xeon 6 Processors, DDR5 Memory, NVMe BOSS, Energy Star compliant and advanced cooling.Ideal for:
• Data services
• Cloud scale web and app microservices
• Virtualization
• Scale-out database
|
Processor |
One Intel® Xeon 6 E- core processor with up to 144 cores per processor or One Intel® Xeon 6 P- core processor with up to 86 Cores with R1S option. |
|
Memory |
• 16 DDR5 DIMM slot, supports RDIMM 4TB* max, speeds up to 6400 MT/s • Intel® Xeon® 6 E-core processor - supports 1 TB max •Intel® Xeon® 6 P-core processor with up to 86 cores with R1S option - supports 4 TB max* • Supports registered ECC DDR5 DIMMs only |
|
Storage controllers |
• Internal Controllers (RAID): PERC H365i DC-MHS, front PERC H965i DC-MHS, PERC H365i adapter*, PERC H965i adapter* • External Controllers: HBA465e*, H965e*(RAID) • Internal Boot: Boot Optimized Storage Subsystem (BOSS-N1 DC-MHS): HWRAID 1, 2 xM.2 NVMe |
|
Drive bays |
Front bays: • Up to 8 x EDSFF E3.S Gen5 NVMe (SSD) max 122.88 TB • Up to 16 x EDSFF E3.S Gen5 NVMe (SSD) max 245.76 TB* • Up to 8 x 2.5-inch SAS/SATA/NVMe (SSD) max 122.88 TB • Up to 10 x 2.5 - inch SAS/SATA/NVMe(SSD) (with 4 x 2.5 -inch universal) max 84.48 TB • Up to 4 x 3.5 - inch SAS/SATA max 96 TB* Rear bays: • Up to 2 x EDSFF E3.S Gen5 NVMe (SSD) max 30.72 TB |
|
Power Supplies |
• 800W Platinum 100-240 VAC or 240 HVDC, hot swap redundant • 1100 W Platinum/Titanium 100-240 VAC or 240 HVDC, hot swap redundant • 1500 W Titanium 100-240 VAC or 240 HVDC, hot swap redundant • 1500W Titanium 100-240 VAC or 240 HVDC, hot swap redundant • 1500 W 277 Vac and HVDC Titanium, hot swap redundant** • 1400W -48v DC Titanium, hot swap redundant* |
|
Cooling Options |
Air cooling |
|
Fans |
• Up to 4 sets (dual fan module) hot swappable fans |
|
Dimensions |
• Height – 42.8 mm (1.69 inches) • Width – 482 mm (19.0 inches) • Depth – 816.92 mm (32.16 inches) with bezel • Depth – 815.14 mm(32.09 inches) without bezel • Depth (Front I/O Configuration) — 829.44 mm (32.09 inches) without bezel |
|
Form Factor |
1U rack server |
|
Embedded Management |
• iDRAC • iDRAC Direct • iDRAC RESTfull API with redfish • RACADM CLI • iDRAC Service Module |
|
Bezel |
Optional security bezel |
|
Security |
• Cryptographically signed firmware • Data at Rest Encryption (SEDs with local or external key mgmt) • Secure Boot • Secured Component Verification (Hardware integrity check) • Secure Erase • Silicon Root of Trust • System Lockdown (requires iDRAC10 Enterprise or Datacenter) • TPM 2.0 FIPS, CC-TCG certified • Chassis Intrusion Detection |
|
GPU Options |
Up to 4 x 75 W SW |
|
Ports |
Front Ports • 1 x USB 2.0 Type - C port • 1 x USB 2.0 Type A port (optional) • 1 x Mini-DisplayPort (optional) • 1 x DB9 Serial (with front I/O configuration) • 1 x Dedicated BMC Ethernet port (with front I/O configuration) Rear Ports • 1 x Dedicated BMC Ethernet port • 2 x USB 3.1 Type A ports • 1 x VGA Internal Port • 1 x USB 3.1 Type A port |
|
PCIe |
Up to 4 Gen5 PCIe slots (x16 connectors) • Slot 1 -1 x8 Gen5 Low Profile • Slot 1 -1 x16 Gen5 (x16 connector) full height, half length on rear riser • Slot 4 -1 x16 Gen5 (x16 connector) full height, half length on rear riser • Slot 31 -1 x16 Gen5 (x16 connector) full height, half length on rear riser* • Slot 32 -1 x16 Gen5 (x16 connector) full height, half length on rear riser |
The Dell PowerEdge R470 is powered by Intel Xeon 6 Processors, DDR5 Memory, NVMe BOSS, Energy Star compliant and advanced cooling.Ideal for:
• Data services
• Cloud scale web and app microservices
• Virtualization
• Scale-out database
Driving energy efficiencies in large-scale data centres
The Dell PowerEdge R470 is designed to maximise efficiencies in your data centre.
Purpose-built to boost datacentre productivity
The Dell PowerEdge R470 is a 1U, one-socket rack server engineered for high-performance computing with optimal power efficiency and balanced performance, driving cost savings and boosting data centre productivity. Its advanced design maximises rack utilisation by offering more cores in a single socket enabling better performance in a smaller footprint while minimising energy consumption. This makes it ideal for workloads like cloud scale web and app microservices, data services, virtualisation, and scale-out database.
• Purpose-built to scale infrastructure to adapt seamlessly to technological changes, integrating new capabilities that support long-term growth and innovation.
• Powered by Intel® Xeon® 6 processors designed to meet diverse performance and efficiency requirements and offered with advanced GPU support.
• Enhanced I/O flexibility with optional front I/O configuration for seamless cold aisle serviceability.
• Energy-efficient designs with Smart Power and Cooling deliver cost savings and peak performance.
• Configurable to suit diverse needs with industry standard open designs (DC-MHS) compliance.
Systems management and security solutions
OpenManage systems management
Tame the complexity of your IT environment with Dells
Technologies’ OpenManage systems management portfolio which uses tools and solutions to discover, deploy, monitor, manage, update and secure your PowerEdge infrastructure.
Intelligent automation
Integrate tools across your portfolio with PowerEdge iDRAC, OpenManage Enterprise and CloudIQ solutions that help organisations automate their server lifecycles, optimise operations and scale efficiently.
Built-in security
Stay protected at every phase of the product lifecycle with the PowerEdge cyber resilient architecture that helps accelerate your adoption of a Zero Trust security strategy. From the silicon root of trust, signed firmware and verification, secured component drift detection to BIOS recovery and dynamic system lockdown, you can rest assured that your servers are secure.
