The new PowerEdge R6625 is a 1U, dual-socket rack server. Designed to be the backbone of your data center, this powerful server provides ample performance and flexible, low-latency storage options in a dense air or Direct Liquid Cooling (DLC) configuration.
The new PowerEdge R6625 is a 1U, dual-socket rack server. Designed to be the backbone of your data center, this powerful server provides ample performance and flexible, low-latency storage options in a dense air or Direct Liquid Cooling (DLC) configuration.
Features:
•Stay ahead of the curve
•Extreme performance in a platform that grows with your business
•Experience more virtual machine density to support the most demanding application
•Expect increased expandability by storing more data in one server, saving space in your datacenter
•Cyber Resilient Architecture for Zero Trust IT environment & operations
•Increase efficiency and accelerate operations with an autonomous infrastructure
•Sustainability
•Rest easier with Dells Technologies Services
|
MODEL |
PowerEdge R6625 rack server |
|
Processor |
Up to two AMD EPYC 4th Generation 9004 Series with up to 128 cores per processor |
|
Memory |
• 24 DDR5 DIMM slots, supports RDIMM 6 TB max, speeds up to 4800 MT/s • Supports registered ECC DDR5 DIMMs only |
|
Storage controllers |
• Internal Controllers: PERC H965i, PERC H755, PERC H755N, PERC H355, HBA355i • Internal Boot: Boot Optimized Storage Subsystem (BOSS-N1): HWRAID 2 x M.2 NVMe SSDs or USB • External HBA (non-RAID): HBA355e • Software RAID: S160 |
|
|
Front bays: • Up to 4 x 3.5-inch SAS/SATA (HDD/SSD) max 80 TB • Up to 8 x 2.5-inch NVMe (SSD) max 122.88 TB • Up to 10 x2.5-inchSAS/SATA/NVMe (HDD/SSD) max 153.6 TB • Up to 14 x E3.S NVMe direct drives max 107.52 TB • Up to 16 x E3.S NVMe direct drives max 122.88 TB Rear bays: • Up to 2 x 2.5-inch SAS/SATA (HDD/SSD) max 30.72 TB • Up to 2 x E3.S NVMe direct drives max15.36.8 TB |
|
Power Supplies |
• 1800 W Titanium 200—240 VAC or 240 HVDC, hot swap redundant • 1400 W Mixed Mode Platinum 100-240 VAC or 240 HVDC hot swap redundant • 1400 W Mixed Mode Titanium 277 VAC or 336 HVDC hot swap redundant • 1100 W Mixed mode 100—240 VAC or 240 HVDC, hot swap redundant • 1100 W LVDC -48 — -60 VDC, hot swap redundant • 800 W Platinum 100—240 VAC or 240 HVDC , hot swap redundant |
|
Cooling Options |
• Air cooling • Optional Direct Liquid Cooling (DLC) Note: DLC is a rack solution and requires rack manifolds and a cooling distribution unit (CDU) to operate. |
|
Fans |
• Standard (STD) fans/High performance Gold (VHP) fans • Up to 4 sets (dual fan module) hot plug fans |
|
Dimensions |
• Height – 42.8 mm (1.685 inches) • Width – 482.0 mm (18.97 inches) • Depth – 822.89 mm (32.4 inches) with bezel 809.05 (31.85 inches) without bezel |
|
Form Factor |
1U rack server |
|
Embedded Management |
• iDRAC9 • iDRAC Direct • iDRAC RESTful API with Redfish • iDRAC Service Manual • Quick Sync 2 wireless module |
|
Bezel |
Optional LCD bezel or security bezel |
|
OpenManage Software |
• OpenManage Enterprise • OpenManage Power Manager plugin • OpenManage Service plugin • OpenManage Update Manager plugin •CloudIQ for PowerEdge plug in • OpenManage Enterprise Integration for VMware vCenter • OpenManage Integration for Microsoft System Center • OpenManage Integration with Windows Admin Center |
|
Mobility |
OpenManage Mobile |
|
OpenManage Integrations |
• BMC Truesight • Microsoft System Center • OpenManage Integration with ServiceNow • Red Hat Ansible Modules • Terraform Providers • VMware vCenter and vRealize Operations Manager |
|
Security |
• AMD Secure Encrypted Virtualization (SEV) • AMD Secure Memory Encryption (SME) • Cryptographically signed firmware • Data at Rest Encryption (SEDs with local or external key mgmt) • Secure Boot • Secured Component Verification (Hardware integrity check) •Secure Erase • Silicon Root of Trust • System Lockdown (requires iDRAC9 Enterprise or Datacenter) • TPM 2.0 FIPS, CC-TCG certified, TPM 2.0 China NationZ |
|
Embedded NIC |
2 x 1GbE LOM card (optional) |
|
Network Options |
1 x OCP 3.0 card (optional) Note: The system allows either LOM card or an OCP card or both to be installed in the system. |
|
GPU Options |
3 x 75 W SW |
|
Ports |
Front Ports • 1 x iDRAC Direct (Micro-AB USB) port • 1 x USB 2.0 • 1 x VGA Rear Ports • 1 x Dedcated iDRAC Ethernet port • 1 x USB 3.0 • 1 x USB 2.0 • 1 x Serial (optional) • 1 x VGA (optional for Direct Liquid Cooling configuration) |
|
PCIe |
Up to three PCIe slots Rear Ports • 1 x Dedcated iDRAC Ethernet port • 1 x USB 3.0 • 1 x USB 2.0 • 1 x Serial (optional) • 1 xVGA (optional for Direct Liquid Cooling configuration) • Slot 1: 1 x16 Gen5 or 1 x16 Gen4 Low profile, Half length or 1 x16 Gen5 Full height, Half length • Slot 2: 1 x16 Gen5 or 1 x16 Gen4 Low profile, Half length or 1 x16 Gen5 Full height, Half length • Slot3: 1 x16 Gen5 or1 x16 Gen4 Low profile, Half length |
|
Operating System and Hypervisors |
• Canonical Ubuntu Server LTS • Microsoft Windows Server with Hyper-V • Red Hat Enterprise Linux • SUSE Linux Enterprise Server •VMware ESXi |
