PowerEdge XE servers are acceleration-optimized, purpose-built for Artificial Intelligence (AI), Generative AI (GenAI), and High Performance Computing (HPC). With superior acceleration and diverse GPU options, these powerful platforms are optimized to turn ideas into action faster.
PowerEdge XE servers are acceleration-optimized, purpose-built for Artificial Intelligence (AI), Generative AI (GenAI), and High Performance Computing (HPC). With superior acceleration and diverse GPU options, these powerful platforms are optimized to turn ideas into action faster.
No-compromise accelerated AI
Rapidly develop, train and deploy large machine learning models with this high-performance application server designed for HPC super computing clusters and the largest data sets for AI, used for large scale natural language processing, recommendation engines and neural network applications.
Customization & Services
Professional guidance to address individual customer needs, from defining goals and designing architectures, to building AI models
Intelligent Automation
Simplify and automate management and monitoring with iDRAC, OME support and CloudIQ for AIOps
Security
Built - in platform security features, including Secured Component Verification and Silicon Root of Trust
Partners
Turnkey AI solutions with expansive partner ecosystem including Hugging Face, Meta, NVI DIA, SI
Efficiently drive traditional AI training, HPC and data analytics applications with four high performance accelerators and air - cooling. Get the ultimate balance of performance, power and price with Intel® CPUs and the newest NVIDIA® H100 Tensor Core GPUs.
* Drive a wide range of AI workloads with two powerful 4th generation Intel® Xeon® processors and four NVIDIA® H100 GPUs interconnected with NVLink®
* Built for dense inferencing in fields like oil and gas, finance and healthcare
* Boost performance with DDR5 memory and PCIe Gen5 support
* Support for the highest wattage next - gen technologies up to 35°C ambient temperature with a 4U air - cooled design
Transform your business
Strike the perfect balance between performance, power and cost when deploying a solution to suit your IT strategy.
* Next generation NVIDIA® GPUs achieve superior AI performance in medical imaging, business decision making applications and most other applications
* Get continuous data processing and faster I/O performance with GPU Direct Storage transfers, bypassing server CPUs
* Scale with confidence thanks to support for up to 32 DDR5 memory DIMM slots, up to eight drives and up to 4 PCIe Gen 5 expansion slots
|
Processor |
• Two 5th Generation Intel Xeon Scalable processors with up to 64 cores per processor • Two 4th Generation Intel Xeon Scalable processors with up to 56 cores per processor |
|
Memory |
• 32 DDR5 DIMM slots, supports RDIMM 4 TB max, speeds up to 5600 MT/s • Supports registered ECC DDR5 DIMMs only |
|
GPU |
• 4 NVI DIA HGX H100 80GB 700W SXM5 GPUs, fully interconnected with NVI DIA NVLink technology |
|
Storage controllers |
• Internal controller: PERC H965i • Internal boot: Boot Optimized Storage Subsystem (NVMe BOSS-N1): HWRAID 1, 2 x M.2 SSDs • Software RAID: S160 |
|
Drive bays |
Front Bays • Up to 8 x 2.5-inch SATA/SAS/NVMe SSD max 122.88 TB • Up to 8 x E3.S NVMe SSD max 122.88 TB |
|
Power Supplies |
2800W Titanium 200-240 VAC or 240 VDC, redundant, hot swap 3200W Titanium 277 VAC or 260-400 VDC redundant, hot swap |
|
Cooling Options |
• Air cooling for Processors • Liquid Assisted Air Cooling for GPU |
|
Chipset |
Intel® C741 chipset |
|
PCIe |
2 CPU configuration: Up to 4 PCIe slots (4 x16 Gen5) |
|
Embedded NIC |
2 x 1 GbE |
|
Network Options |
1 x OCP 3.0 (x8 PCIe lanes) |
|
Fans |
• Up to 6 Standard (STD) fans installed in mid tray • Up to 5 High performance (HPR) gold grade fans installed on the front of the system • All are hot swap fans |
|
Dimensions and weight |
• Height — 174.3 mm (6.86 inches) • Width — 481.91 mm (18.97 inches) • Depth — 901.4 mm (35.48 inches) with bezel — 865.54 mm(34.07 inches) inch without bezel • Weight — 61.4 kg (135.36 pounds) |
|
Form Factor |
4U rack server |
|
Embedded Management |
• iDRAC9 • iDRAC Direct |
|
Ports |
Front ports • 1 x iDRAC Direct (Micro-AB USB) port • 1 x VGA |
Systems management and security solutions
Tame the complexity of your IT environment with Dells
Technologies’ OpenManage systems management portfolio which uses tools and solutions to discover, deploy, monitor, manage, update and secure your PowerEdge infrastructure.
Integrate tools across your portfolio with PowerEdge iDRAC,
OpenManage Enterprise and CloudIQ solutions that help organisations automate their server lifecycles, optimise operations and scale efficiently.
Stay protected at every phase of the product lifecycle with the PowerEdge cyber resilient architecture that helps accelerate your adoption of a Zero Trust security strategy. From the silicon root of trust, signed firmware and verification, secured component drift detection to BIOS recovery and dynamic system lockdown, you can rest assured that your servers are secure.
