Looking for seriously simple and affordable flash storage? The HPE MSA 2062 Storage is a flash-enabled system designed for affordable application acceleration for small and remote office deployments. Don’t let the low cost fool you. The HPE MSA 2062 gives you the combination of simplicity, flexibility and advanced features you may not expect in an entry-priced storage array. Starting with 3.84 TB of embedded flash capacity, you can scale the system from there with any combination of solid state disks (SSD), high-performance Enterprise SAS HDDs, or lower-cost Midline SAS HDDs. Capable of delivering up to 395,000 IOPS, the HPE MSA 2062 saves you up to 26% with an allinclusive software suite and 3.84 TB of flash capacity included. It’s seriously simple and affordable flash storage to help you achieve high performance yet meet challenging budgets
What's new
· HPE MSA 24TB SAS LFF HDD option available as a single drive or 6-pack HDD bundle. Increases MSA 2062 array maximum raw capacity to 2.76PB with up to 9 additional MSA 2060 LFF Drive Enclosures added.
· HPE MSA Storage certification as a Backup Repository to provide seamless protection and Instant VM Recovery with Veeam Backup and Replication.
· NEBS certification for HPE MSA Gen6 16Gb FC and 12Gb SAS SFF storage arrays and the MSA 2060 SFF Drive Enclosure.
· Add 25 Gb iSCSI host connectivity support to your HPE MSA 2062 Array with the new HPE MSA 25 Gb SFP28 Short Range 4pack of iSCSI Transceivers.
· New 18 TB capacity 7.2K LFF SAS hard drive, single drive and six-pack options, available for 2062 LFF array models and 2060 LFF expansion drive enclosures.
Affordable Application Acceleration
The HPE MSA 2062 Storage is capable of delivering over 395,000 IOPS for affordable application acceleration for small to medium-sized businesses. Save up to 26% on HPE MSA 2062 with all-inclusive software and 3.84 TB of Solid State Drive (SSD) capacity included.
HPE MSA’s 'Set It and Forget IT' Data Services Does not Require a Dedicated Storage Administrator
The HPE MSA 2062 Storage is easy to install, easy to use, easy to maintain, even for an IT generalist. Administrators will find the HPE MSA 2062’s new Storage Management Utility intuitive and easy to navigate.
HPE MSA’s automated tiering engine dynamically responds to workload changes so you don’t have to, ensuring the hottest data will be moved to the fastest media automatically and in real-time.
Leverage Data Protection Features to Keep your Business Running in the Event of a Disaster
The HPE MSA 2062 Storage delivers virtualized snapshot technology making data protection and instant recovery a snap.
Remote replication via Fibre Channel (FC) or iSCSI facilitates affordable disaster recovery solution.
Encrypted SSDs and HDDs with local key management can be deployed to deliver a secure, encrypted hybrid flash array.
Flexible, Modular Architecture that Facilitates Growth into the Future
The HPE MSA 2062 Storage solution supports a mixture of 3.5 inch LFF and 2.5 inch SFF 2060 expansion drive enclosures for a maximum of 9 enclosures (10 in total including the array).
Start small and scale as needed with any combination of SSDs, Enterprise SAS or MidLine SAS HDDs.
| Drive description | Up to 12 LFF or 24 SFF HDD and/or SSD per array or drive enclosure, depending on selected model |
| Capacity | 1.83 PB (all SFF expansion) to 2.76 PB (all LFF expansion) with maximum expansion depending on model and configuration |
| Host interface | 16 Gb Fibre Channel, 10/25GbE iSCSI, 10GBase-T iSCSI, or 12 Gb SAS depending on model |
| Storage controller | 2 controllers per array, 4-ports per controller (8-ports total) |
| Compatible operating systems |
Windows Server®; VMware vSphere™; Red Hat® Linux; SUSE™ SLES; See HPE SPOCK for more details. |
| Form factor | 2U |
| Product dimensions (metric) |
8.9 x 44.5 x 50.8 cm Weight 5.0 kg |
| Warranty | Three-year limited warranty, parts exchange next business day delivery. Disk enclosures, hard drives and options carry their own warranty. |
