Huawei CloudEngine S5335-L-V2 Series Switches

Huawei CloudEngine S5335-L-V2 series are simplified gigabit Ethernet switches that provide all GE downlink ports,10GE uplink ports, and dedicated stacking ports.

Description
Product Parameters

huawei cloudengine s5335 l v2 series switches-2

+86-18600585382

[email protected]

Description

Product description

Based on new-generation high-performance hardware and Huawei's unified software platform, the CloudEngine S5735-L-V2 series switches feature flexible Ethernet networking, diverse security controls, and easy operation and maintenance, and support a variety of Layer 3 routing protocols with higher performance and richer service processing capabilities, which are widely used in various industries such as healthcare, retail, mining, and Internet.

Feature

Variety of product forms

Provide 8/10/16/24/48 Gigabit port models to meet the needs of different scenarios to build networks

Multiple safety controls

The device supports MAC, 802.1x authentication and hybrid authentication to achieve dynamic issuance of user policies (VLAN, QoS,ACL)
Supports perfect DoS-type anti-attack and user-type anti-attack.

Network Intelligent Operation and Maintenance

Support Telemetry technology, real-time collection of device data, with the park network analyser timely detection of network problems affecting user experience, accurate protection of user experience.

Product Parameters

	CloudEngine S5735-L8T4S-A-V2	CloudEngine S5735-L8P4S-A-V2	CloudEngineS5735-L10T4X-A-V2	CloudEngineS5735-L8P2T4X-A-V2
Dimensions (W x D x H)	25018043.6MM	32021043.6MM	25018043.6MM	32021043.6MM
Chassis height [U]	1U	1U	1U	1U
Exchange capacity	672Gbps/6.72Tbps	672Gbps/6.72Tbps	672Gbps/6.72Tbps	672Gbps/6.72Tbps
Packet forwarding rate	102Mpps	102Mpps	105Mpps	105Mpps
fixed port	8 10/100/1000BASE-T Ethernet ports, 4 Gigabit SFPs	8 10/100/1000BASE-T Ethernet ports, 4 Gigabit SFPs	10 10/100/1000BASE-T Ethernet ports, 4 10 Gigabit SFP+	8 10/100/1000BASE-T Ethernet ports (PoE+), 2 10/100/1000BASE-T Ethernet ports, 4 10 Gigabit SFP+
POE capability	unsupported	Support	unsupported	Support
full complementary weight	2.22kg	3.05kg	2.22kg	3.06kg
Power supply type	Built-in AC power supply	Built-in AC power supply	Built-in AC power supply	Built-in AC power supply
Rated Input Voltage [V]	100VAC~240VAC; 50HZ~60HZ	100VAC~240VAC; 50HZ~60HZ	100VAC~240VAC; 50HZ~60HZ	100VAC~240VAC; 50HZ~60HZ
Maximum voltage	Ac input :90VAC~264VAC; 45HZ~65HZ	Ac input :90VAC~264VAC; 45HZ~65HZ	Ac input :90VAC~264VAC; 45HZ~65HZ	Ac input :90VAC~264VAC; 45HZ~65HZ
operating temperature [°C]	-5°C~+50°C	-5°C~+50°C	-5°C~+50°C	-5°C~+50°C
Storage temperature [°C]	-40℃~+70℃	-40℃~+70℃	-40℃~+70℃	-40℃~+70℃
Long-term working environment relative humidity [RH]	5%RH to 95%RH, non-condensation	5%RH to 95%RH, non-condensation	5%RH to 95%RH, non-condensation	5%RH to 95%RH, non-condensation
Heat dissipation method	Air-cooled heat dissipation, intelligent speed regulation	Air-cooled heat dissipation, intelligent speed regulation	Air-cooled heat dissipation, intelligent speed regulation	Air-cooled heat dissipation, intelligent speed regulation
