Highest density per core ideal for:
• Virtualization with lower licensing cost
• Hyper-Converged Infrastructure (HCI)
Highest density per core ideal for:
• Virtualization with lower licensing cost
• Hyper-Converged Infrastructure (HCI)
|
Processor |
One 5th Generation AMD EPYC 9005 Series processor with up to 160 cores per processor |
|
Memory |
• 24 DDR5 DIMM slots, supports RDIMM 6 TB max*, speeds up to 5200 MT/s • Supports registered ECC DDR5 DIMMs only |
|
Storage controllers |
• Internal Controllers (RAID): PERC H365i, H965i, H975i* • Internal Boot: Boot Optimized Storage Subsystem (BOSS-N1 DC-MHS) •External HBAs (non-RAID): HBA465e |
|
Drive bays |
Front bays: • 2 x U.2 • 12 x 3.5-inch SAS/SATA* • 8 x 2.5 Universal/ 16 x 2.5-inch SAS/SATA / 24 x 2.5-inch SAS/SATA* • 16 x 2.5-inchSAS/SATA SSD + 8 x U.2 NVMe drives • 8 x EDSFF E3.S / 16 x EDSFF E3.S / 32 x EDSFF E3.S / 40 x EDSFF E3.S |
|
Power Supplies |
• Platinum 800W, 1100W • Titanium: 800W, 1100W, 1500W, 1500W 277Vac & HVDC**, 1800W**, 2400W**, 3200W, 3200W 277Vac & HVDC** •Telco: 1400W -48VDC |
|
Cooling Options |
Air cooling, Direct Liquid Cooling (DLC) |
|
Fans |
• Up to six hot plug fans |
|
Dimensions |
• Height – 86.8 mm (3.41 inches) • Width – 482.0 mm (18.97 inches) • Depth – 802.4 mm (31.59 inches) with bezel 801.51 mm (31.55inches) without bezel |
|
Form Factor |
2U rack server |
|
Embedded Management |
• iDRAC10 • iDRAC Direct • iDRAC RESTful API with Redfish • Racadm CLI |
|
Bezel |
Optional metal bezel |
|
OpenManage Console |
• OpenManage Enterprise (OME) • OME Power Manager • OME Services • OME Update Manager • OME Integration for VMware vCenter (with VMware Aria Operations) • OpenManage Integration for Microsoft System Center • OpenManage Integration for Windows Admin Center |
|
GPU Options |
Up to 3x 400W DW; Up to 6x 75W SW |
|
Ports |
Front Ports • 1 x USB 2.0 Type-A (optional LCP KVM) • 1 x USB 2.0 Type-C (HOST/BMC Direct) • 1 x MiniDisplay port (optional LCP KVM) Rear Ports • 1 x 1 Gb Dedicated BMC Ethernet port • 2 x USB 3.1 Type-A • 1 x VGA Internal Port • 1 x USB 3.1 Type-A |
|
PCIe |
Up to eight PCIe slots (x16 connectors) • Slot 1: 1 x16 Gen5 Full Height Rear Ports • 1 x 1 Gb Dedicated BMC Ethernet port • 2 xUSB 3.1 Type-A • 1 x VGA • Slot 2: 1 x16 Gen5 Full Height or 1 x16 Dual Width Full Length • Slot 3: 1 x16 Gen5 Full Height or Low Profile • Slot 4: 1 x16 Gen5 Full Height or 1 x16 Dual Width Full Length or 1 x16 OCP3.0 • Slot 5: 1 x16 Gen5 Full Height • Slot 7: 1 x16 Gen5 Full Height or 1 x16 Dual Width Full Length • Slot 8: 1 x16 Gen5 Full Height • Slot 9: 1 x16 Gen5 Full Height or Low Profile |
Accelerate time to transformation
The PowerEdge R7715 is perfect for high-requirement data applications with one AMD EPYC™ 9005 Series processor, up to 8x PCIe Gen5 slots[1], dual OCP, and DDR5 memory.
Exceptional performance and efficiency
Great flexibility with multiple configuration options to suit diverse business requirements
* Powered by one AMD EPYC™ 5th generation processor
* Up to 24x DDR5 RDIMMs (up to 3 TB)
Systems management and security solutions
OpenManage systems management
Tame the complexity of your IT environment with Dells
Technologies’ OpenManage systems management portfolio which uses tools and solutions to discover, deploy, monitor, manage, update and secure your PowerEdge infrastructure.
Intelligent automation
Integrate tools across your portfolio with PowerEdge iDRAC, OpenManage Enterprise and CloudIQ solutions that help organisations automate their server lifecycles, optimise operations and scale efficiently.
Built-in security
Stay protected at every phase of the product lifecycle with the PowerEdge cyber resilient architecture that helps accelerate your adoption of a Zero Trust security strategy. From the silicon root of trust, signed firmware and verification, secured component drift detection to BIOS recovery and dynamic system lockdown, you can rest assured that your servers are secure.
